Product Materials

COVER: 5 ⁄64" (1.9mm) thick steel one-piece cover with white epoxy coating. Cover fixed to the base with four Allen-head screws.

MOTOR: durable, maintenance-free shaded pole motor with safety thermostat and self-resetting thermal cut-off at 266ºF (130ºC). PP UL94-V0 with single inlet fan wheel.

HEATING ELEMENT: waved wire NiCr 40 heating element that incorporates a self-resetting thermal cut-off at 158ºF (70ºC).

ELECTRONIC CONTROL: two distances (15/25 cm) IR electronic detection sensor with zamak air outlet grill.

BASE PLATE: thermoplastic ABS UL 94-V0 base and single-inlet centrifugal scroll fan; with four Ø 5 ⁄16" (8mm) holes for wall mounting.

Installation: Verify all rough-in dimensions prior to installation. Hand dryers require a dedicated circuit and must be properly grounded. GFI Circuit protection is recommended. One side of dryer should be mounted to a stud.

Operation: Place hands 3"−6" below air outlet grill to activate

Warranty:

• Sensors - one (1) year
• Motor Brushes - three (3) years
• All Other Components - ten (10) years.
