The LMIO-102 Digital Partition Interface automatically coordinates lighting controls in flexible spaces with up to four movable walls equipped with contact closures. It is part of a Digital Lighting Management (DLM) system, and can reconfigure connected switches and occupancy sensors.

Features:

• Special Features: UL 2043 Plenum Rated
• Voltage: 24VDC
• Maximum current consumption: 20mA
• Works with third party contact closure inputs
• Recalls 16 configurations for spaces with up to 5 partitioned areas and 4 movable walls
• Four status LEDs indicate if walls are open or closed
• BAA/TAA compliant
• Typical Applications: Hotel and Conference Center, Ballrooms, Meeting Rooms, School Multi-Use Rooms
• Input ratings:
• Input max. sink/source current: 1- 5 mA
• Logic input signal voltage High: >18 VDC
• Logic input signal voltage Low: < 2 VDC

Model:

LMIO-102-U
